Type：CX-IDO-1304B industrial dissolved oxygen meter
Illustrate：Industrial Dissolved Oxygen Meter is the precision instrument used for testing and control of the dissolved oxygen.
CX-IDO-1304B Industrial Dissolved Oxygen Meter
Main Features
1. The instrument has all the parameters of micro-computer storage, computing and compensatingof the related measured values of the dissolved oxygen
2.It can set the relevant data, such as elevation and salinity
4.it is featured by complete functions, stable performance, simple operation and other characteristics, making it an
ideal instrument in the field of the dissolved oxygen testing and control.
5.CX-IDO-1304B Industrial Dissolved Oxygen Meter adopts the backlit LCD display, with error indication
6.The instrument also owns the following features: automatic temperature compensation; isolated 4-20mA current
output; the dual-relay control; high and low points alarming instructions; power-down memory; no back-up
battery; data saved for more than a decade.
Main Parameters
| Measuring range | 0~100.0 ug/L 0~20.00 mg/L 0~60°C |
| Resolution | 0.01 mg/L 0. 01% |
| Accuracy | ±l.5%F.S |
| Control range | 0. 00~19.99mg/L 0.0~199 9％ |
| Temperature compensation range | 0～60°C |
| Output signal | 4-20mA isolated protection output |
| Output control mode | On/Off relay output contacts |
| Relay load | Max. 230V5A (AC); Min. l l5V10A (AC) |
| Current output load | Max. 500 |
| On-ground voltage insulation degree: | minimum load of 500VDC |
| Protection | IP54 |
| Power supply | 220VAC, 50Hz |
| Overall dimension | 186 x 1 31 x 81mm outdoor wall mounting |
| Weight | 1 kg |
| Working conditions | Ambient temperature: 5 - 45 °C,Air relative humidity: ≤ 80% |
| Except for the earth magnetic field, there is no interference of other strong magnetic field around. | |
