Air vortex flow meter

Email:sales01@cxflowmeter.com
whatsapp:008618049841995

Air vortex flowmeter

Today, a customer asked about the selection of air flowmeters. He needed to measure air flow, but the flow range to be measured was relatively large, 0-2000m3/h. The customer did not know how to choose a suitable air flowmeter

He provided us with the following information:

Medium: air,
Pressure 60kpa,
Temperature normal temperature
Flow 0-2000m3/h,
Using one vortex flowmeter cannot measure the full range, multiple vortex flowmeters are required to measure, the smaller the minimum flow, the better, which flowmeters are recommended, and whether to install multiple pipes or one pipe in parallel

After analysis, our technicians told him that there are several options:

Vortex flowmeter, if using conventional type, at least 4 calibers are required:
DN15:4-12 cubic
DN32:15-120 cubic
DN80:80-800
DN15:180-2000


Using high-end type, 3 calibers
DN15:3-18
DN40:14-250
DN80:40-2000

If you choose a thermal flow meter, choose 2 calibers:
DN15:0.65-65
DN65 (high flow rate): 12-2400

It is recommended to install multiple pipes

If you are also confused about the selection of air flow meter and gas flow meter, please consult CIXIFM winny:
Email:sales01@cxflowmeter.com
whatsapp:008618049841995




Last:Coriolis mass flow meter for ul.. Next:air flow meter selection
