Recommendation for Seawater Desalination Pump: CXHP11 Metering Pump

Customer Requirements Summary

• Medium: Seawater
• Temperature: Normal temperature
• Flow Rate: 120–140 liters per minute
• Pressure: 100 kg/cm² (approximately 10 MPa)
• Function: Seawater desalination
• Additional Information Needed: Pump head + motor price, voltage, and power

CXHP11 Metering Pump Specifications



Parameter	Details
Medium	Seawater
Flow Rate	120–140 liters per minute (7.2–8.4 m³/h)
Temperature	Normal temperature
Pressure	100 kg/cm² (Customer Requirement) Pump Specification: 80 bar (8 MPa)
Shell Material	2205 duplex stainless steel
Piston Material	2507 super duplex stainless steel
Typical Speed	1500 rpm
Maximum Flow Rate	11 m³/h
Speed Setting Range	700–1800 rpm
Maximum Outlet Pressure	80 bar (8 MPa)
Power	30 kW / 6 levels
Power Supply	Three-phase 380V, 50 Hz

Key Considerations

1. Pressure Compatibility:
   • The customer requires a pump capable of handling 100 kg/cm² (approximately 10 MPa).
   • The CXHP11 pump has a maximum outlet pressure of 80 bar (8 MPa).
   • Recommendation:
     • Option 1: Explore the possibility of customizing the pump to meet the 100 kg/cm² requirement.
     • Option 2: Use the CXHP11 pump in a multi-stage configuration to achieve the desired pressure.
     • Option 3: Consider integrating a booster pump in the system to supplement the pressure.
2. Flow Rate Compatibility:
   • The CXHP11 pump can handle a flow rate of 120–140 liters per minute (7.2–8.4 m³/h), which is within its maximum flow rate of 11 m³/h.
   • No adjustment needed for flow rate.
3. Material Compatibility:
   • The 2205 duplex stainless steel shell and 2507 super duplex stainless steel piston are highly resistant to corrosion in seawater environments, ensuring long-term durability.
4. Power and Voltage:
   • The pump operates at 30 kW with a three-phase 380V, 50 Hz power supply, which is standard for industrial applications.

Pricing Information

• Pump Head + Motor Price:
  • Please contact our sales team for a detailed quotation based on your specific requirements and any potential customizations needed to meet the 100 kg/cm² pressure requirement.
  • Contact Information:
    • Email: sales01@cxflowmeter.com
    • WhatsApp: +86 180 4984 1995
  •
