Type：620 series Pen type Durometer
Illustrate：OLED superbright display, full angle, G type impact device, suitable for measuring casting and forging pieces that is large, thick, weight and roughness surface. Low voltage warning, USB interface, Bluetooth wireless connected to computer, Bluetooth printer is optional.
CX-PHT-620 Pen type Durometer
Summarize:
OLED superbright display, full angle, G type impact device, suitable for measuring casting and forging pieces that is large, thick, weight and roughness surface. Low voltage warning, USB interface, Bluetooth wireless connected to computer, Bluetooth printer is optional.
Application: steel, case steel, gray pig iron, nodular cast iron.
Parameter:
Measuring range:
Summarize:
OLED superbright display, full angle, G type impact device, suitable for measuring casting and forging pieces that is large, thick, weight and roughness surface. Low voltage warning, USB interface, Bluetooth wireless connected to computer, Bluetooth printer is optional.
Application: steel, case steel, gray pig iron, nodular cast iron.
Parameter:
| Model | PHT-620 |
| Principle | Richter scale hardness measurement method |
| Accuracy | ±4HLG |
| Display | OLED superlight display, full Chinese menu double value operation |
| Hardness scale | HL/HRB/HB ；can add measurement unit according to user’s requirement |
| Measuring range | HLG300-750 / HRB47-100 / HB90-650 |
| Impact device | G type |
| Storage capacity | 400 pcs storage group, can store 36K test data, storage and re-reading |
| Statistics | Average, maximum, minimum |
| Standard | User can calibrate accordingly |
| Warning | Lower power warning |
| Interface | USB interface, Bluetooth |
| Startup & Shutdown | automatical |
| Power supply | Built-in Li battery, chargeable via USD |
| Working temperature | ﹣40℃~+70℃ |
| Overall dimension | 250x47x37mm |
| Net weight | 250g |
| Standard | Accord with GB/T 17394-1998，ASTM A956， DIN 50156 |
Measuring range:
| Impact device G HLG：300-750 | |||
| Test material/hardness | HLG | HRB | HB |
| Steel and cast steel | 300-750 | 47.7-99.9 | 90-646 |
| Gray pig iron | 340-600 | 92-326 | |
| Nodular cast iron | 340-600 | 127-364 | |
| Cast aluminium | 24-85 | 32-168 | |
