Type：CX-FLM-GSK reed switch type float level switch
Illustrate：Application: CX-FLM-GSK series level announciator suit for different kinds of open and low pressure level surface . It can measure the asked level , emit the correct control signal ,alarm and auto-control the startup and stop for the water pump electromotor .
Reed switch type float level switch
Application:
CX-FLM-GSK series level announciator suit for different kinds of open and low pressure level surface .
It can measure the asked level , emit the correct control signal ,alarm and auto-control the startup
and stop for the water pump electromotor .
Advantage :
Simple structure ,stable perform , correct and reliable , different kinds ,guider of announciator .
Float material is good quality stainless steel . This equipment suit for auto-control and alarm for
mine corporation ,civilian building ,cistern ,water tank ,pool. It also can suit for the “three sewage” in
the environment application.
Technical data :
Material :stainless steel ,polypropylene ,PTFE .
Float dimension :Φ120mm Φ100mm Φ75mm Φ70mm Φ45 Φ28
Range:0～6000mm
Working pressure :0～0.6MPa (PVC≤0.25MPa)，anti-explosion type≤1MPa
Medium :clear water ,sewage water ,acid ,alkali ,insulated liquid
Medium temperature:PVC-5℃～+55℃，Stainless steel :-40℃～+100℃
Contact capacity :AC or DC 200V，1A
Note :
1,This control contact can control the AC which is below 220v ,20A . It is the best to through
220VA middle relay converter .
2,It can customize it into anti-explosive type (ExdIIBT4) ,side-mounted , and other un-standard
type ,flange spec and whole material .
